Free sample for Jet Filter Dust Collector - Acrylic Medium Temperature Needle-punched Filter Felt Bag – Xintian
Free sample for Jet Filter Dust Collector - Acrylic Medium Temperature Needle-punched Filter Felt Bag – Xintian Detail:
The DMF- Z electromagnetic pulse valve is a right angle valve with an angle of 90 degrees between the inlet and outlet, which is suitable for the installation and connection of the air bag and dust collector injection tube. The air flow is smooth and can provide the ash cleaning pulse air flow according to the requirement
|
Model No. And Specification |
Nominal Diameter |
Number of diaphragm |
Intake Port Size |
Air Outlet |
Weight (kg) |
|
|
Metric System |
British System |
|||||
|
DMF-Z－20 |
ø20 |
3/4″ |
1 |
G3/4″ |
G3/4″ |
0.65 |
|
DMF-20L-B |
ø20 |
3/4″ |
1 |
G3/4″ |
ø27 |
0.75 |
|
DMF-Z－25 |
ø25 |
1″ |
1 |
G1″ |
G1″ |
0.8 |
|
DMF-Z－40S |
ø40 |
1′/2″ |
2 |
G1′/2″ |
G1′/2″ |
1.4 |
|
DMF-Z－50S |
ø50 |
2″ |
2 |
G2″ |
G2″ |
2.4 |
|
DMF-Z－62S |
ø62 |
2′/2″ |
2 |
G2′/2″ |
G2′/2″ |
3.5 |
|
DMF-Z－76S |
ø76 |
3″ |
2 |
G3″ |
G3″ |
4.3 |
|
DMF-Z－102S |
ø102 |
4″ |
2 |
G4″ |
G4″ |
7.3 |
Product detail pictures:
