*Introduction to related knowledge of filter cartridge dust collector

Introduction to the working principle of the filter bucket dust collector:

After the dust-containing gas enters the dust hopper of the dust collector, due to the sudden expansion of the air flow section and the effect of the air distribution plate, a part of the coarse particles in the air flow settle in the ash hopper under the action of dynamic and inertial forces; the fine particle size and low density dust particles enter the dust filter chamber , Through the combined effects of Brownian diffusion and sieving, the dust is deposited on the surface of the filter material, and the purified gas enters the clean air chamber and is discharged by the exhaust pipe through the fan.

Introduction to the structure of filter cartridge dust collector:

1. According to the overall structure, the filter cartridge dust collector is mainly composed of six parts: the upper box, the ash bucket, the ladder platform, the bracket, the pulse cleaning and the ash discharge device.

2 The general filter cartridge dust collector adopts a vertical structure, because this structure design helps to absorb dust and clean dust, and can reduce the jitter rate, and the maintenance is relatively simple.

3. The dust removal method of the dust collector is very important. Therefore, in order to avoid the problem of re-adsorption during the dust removal of the dust collector, most of the filter cartridge dust collector will use the offline dust removal method and separate spray cleaning. technology.

4. The main function of the dust collector is to remove dust, so there is a pre-dust collection mechanism in the functional design, which can overcome the shortcomings of direct dust washing and easy to wear the filter cartridge, and can greatly increase the dust concentration at the entrance of the dust collector.

5. Purify the air in the room. After cleaning the dust by the filter cartridge dust collector, you should open the clean air outlet channel after a few seconds, so as to clean the dust more thoroughly. The arrangement of the filter cartridge in the dust collector is very important. It can be arranged vertically on the flower plate of the box body or inclined on the flower plate. From the perspective of the cleaning effect, the vertical arrangement is more reasonable. The lower part of the flower plate is the filter chamber, and the upper part is the air box pulse chamber. An air distribution plate is installed at the entrance of the filter cartridge dust collector.

6. Once the dust is adsorbed on the outer surface of the filter cartridge, the filtered gas should enter the clean air cavity of the upper box and be collected to the air outlet to be discharged to avoid polluting the clean air.

7. The service life of the filter cartridge dust collector is not too short. Generally speaking, it can be used for up to 2 to 3 years. If it is properly maintained and the filter element is replaced regularly, it will be more useful.
