Quality Inspection for Esp Electrostatic - HMC series pulse cloth bag dust collector – Xintian Detail:
HMC series pulse cloth bag dust collector is a single type bag dust collector. It adopts circular filter bag, self-contained air ventilation system with pulse injection ash cleaning mode, which has advantages of high dust removal efficiency, good ash cleaning effect, low operation resistance, long service life of filter bag, simple maintenance and stable operation, etc.
When the dust gas enters into the cloth bag dust collector from air induced system, due to the decrease of wind speed, the dust particles with a large proportion settle into the ash hopper, and the lighter dust depends on the air induction to reach the surface of dust removal filter bag. The filter bag of dust collector generally uses needle felt as the filter carrier, and the filtration accuracy can reach <1um. The dust is blocked on the surface by the filter bag, and the dust gas is purified through the filter bag. With the increasing of time, more and more dust is filtered on the surface of filter bag, so the resistance of the filter bag is gradually increased. In order to make the dust collector work normally, when the resistance rises to a limited range, the electronic pulse controller issues instructions to follow the order. The sequence triggers each control valve to open the pulse valve, and the compressed air in the gas storage bag of dust collector is sprayed into the corresponding filter bag by each injection hole of the injection pipe. The filter bag expands rapidly under the instantaneous reverse action of air flow, which makes the dust attached to the surface of the filter bag fall off and makes the filter bag achieve the most original air permeability filtration effect. The cleared dust falls into the ash hopper and drains out of the body through the ash removal system to complete the whole ash cleaning and filtration process.
Technical Parameters of Equipment Selection:
|
Equipment Model |
HMC-24 |
HMC-32 |
HMC-36 |
HMC-48 |
HMC-64 |
HMC-80 |
|
|
Total Filtration Area m² |
20 |
25 |
30 |
40 |
50 |
64 |
|
|
Filtration Velocity m³/min |
1.0-2.0 |
||||||
|
Air Volume m³/h |
1200-2400 |
1500-3000 |
1800-3600 |
2400-4800 |
3000-6000 |
3840-7680 |
|
|
Quantity of Filter Bag |
24 |
32 |
36 |
48 |
64 |
80 |
|
|
Specification and Material of Filter Bag |
130*2000mm |
||||||
|
Air Outlet Dust Concentration mg/m³ |
≤30 |
||||||
|
Beard Negative Pressure Pa |
5000 |
||||||
|
Equipment Running Resistance Pa |
800-1200 |
||||||
|
Injection Pressure Mpa |
0.4-0.6 |
||||||
|
Electromagnetic |
Specification |
DMF-Z-25(G1″) |
|||||
|
Quantity |
4 |
4 |
6 |
6 |
8 |
8 |
|
|
Induced Draft Fan Model |
4-72-2.8A |
4-72-3.2A |
4-72-3.6A |
4-72-3.6A |
4-72-4A |
4-72-4.5A |
|
|
Power of Motor |
1.5kw |
2.20kw |
3kw |
4kw |
5.5kw |
7.5kw |
|
Equipment Model: HMC- 160B Pulse Cloth Bag Dust Collector
Application Field: Dust removal of combined grinder, grooving machine, grinding and cutting machine.
|
Equipment Model |
HMC-96 |
HMC-100 |
HMC-120 |
HMC-160 |
HMC-200 |
HMC-240 |
|
|
Total Filtration Area m² |
77 |
80 |
96 |
128 |
160 |
192 |
|
|
Filtration Velocity m³/min |
1.0-2.0 |
||||||
|
Air Volume m³/h |
4620-9240 |
4800-9600 |
5760-11520 |
7680-15360 |
9600-19200 |
11520-23040 |
|
|
Quantity of Filter Bag |
96 |
100 |
120 |
160 |
200 |
240 |
|
|
Specification and Material of Filter Bag |
130*2000mm |
||||||
|
Air Outlet Dust Concentration mg/m³ |
≤30 |
||||||
|
Beard Negative Pressure Pa |
5000 |
||||||
|
Equipment Running Resistance Pa |
800-1200 |
||||||
|
Injection Pressure Mpa |
0.4-0.6 |
||||||
|
Electromagnetic |
Specification |
DMF-Z-25(G1″) |
|||||
|
Quantity |
12 |
10 |
12 |
16 |
20 |
20 |
|
|
Induced Draft Fan Model |
4-72-4.5A |
4-72-4.5A |
4-72-5A |
4-72-5A |
4-68-8C |
4-68-6.3C |
|
|
Power of Motor |
7.5kw |
7.5kw |
11kw |
15kw |
18.5kw |
22kw |
|
Product detail pictures:
Related Product Guide:
Together with the "Client-Oriented" enterprise philosophy, a arduous good quality control technique, sophisticated producing equipment and a sturdy R&D staff, we generally offer superior quality merchandise, superb solutions and aggressive rates for Quality Inspection for Esp Electrostatic - HMC series pulse cloth bag dust collector – Xintian , The product will supply to all over the world, such as: Guinea, Chile, Iceland, So that you can utilize the resource from the expanding info in international trade, we welcome shoppers from everywhere on-line and offline. In spite of the good quality solutions we offer, effective and satisfying consultation service is supplied by our specialist after-sale service team. Product lists and detailed parameters and any other info weil be sent to you timely for your inquiries. So please make contact with us by sending us emails or call us if you have any questions about our corporation. ou may also get our address info from our web page and come to our company to get a field survey of our merchandise. We are confident that we are going to share mutual achievement and create strong co-operation relations with our companions in this marketplace. We're searching forward for your inquiries.
By Myrna from Paraguay - 2018.06.09 12:42
This company can be well to meet our needs on product quantity and delivery time, so we always choose them when we have procurement requirements.
By Charlotte from Slovenia - 2017.11.20 15:58
Related products
-
2021 Good Quality Pulse Jet Solenoid Valve Work...
The waterproof grade of polyester two-pruned felt filter bag reaches level. It also ensures that the polyester two-pruned felt filter bag is not easy to block in the environment with large humidity, which greatly increases the service life of the filter bag and reduces the difficulty of manual operation. At the same time, the surface of the polyester two-prick needle-proof felt filter bag is smooth and the air permeability is good, which ensures the characteristics of the outer filter surface...
-
factory low price Electrical Precipitation Of S...
Under ordinary operating conditions, the centrifugal force acting on the particles is 5 ~ 2500 times that of gravity, so the efficiency of cyclone dust collector is significantly higher than that of gravity settling chamber. Based on this principle, a cyclone dust removal device with dust removal efficiency of more than 90 percent has been successfully studied. Among the mechanical dust removers, the cyclone dust remover is the most efficient one. It is suitable for the removal of non-visc...
-
New Delivery for Wesp Wet Electrostatic Precipi...
