Reasonable price for In Electrostatic Precipitator - Cyclone Dust Collector – Xintian

Short Description:


Product Detail

Product Tags

Related Video

Feedback (2)

It truly is our responsibility to fulfill your requirements and successfully provide you. Your fulfillment is our best reward. We're seeking forward in your check out for joint development for Industrial Bag Filter, Dust Removal Equipment, Electrostatic Precipitator For Air Pollution Control, Please don't hesitate to contact us if you are interested in our products. We firmly believe our products will make you satisfied.
Reasonable price for In Electrostatic Precipitator - Cyclone Dust Collector – Xintian Detail:

Product description

Under ordinary operating conditions, the centrifugal force acting on the particles is 5 ~ 2500 times that of gravity, so the efficiency of cyclone dust collector is significantly higher than that of gravity settling chamber. Based on this principle, a cyclone dust removal device with dust removal efficiency of more than 90 percent has been successfully studied. Among the mechanical dust removers, the cyclone dust remover is the most efficient one. It is suitable for the removal of non-viscous and non-fibrous dust, mostly used to remove more than 5μm of particles, parallel multi-tube cyclone device for 3μm of particles also has 80 ~ 85% of the dust removal efficiency. The cyclone dust collector is made of special metal or ceramic materials with high temperature resistance, abrasion resistance and corrosion resistance. It can be operated under the conditions of temperature up to 1000℃ and pressure up to 500×105Pa. In terms of technology and economy, the pressure loss control range of cyclone dust collector is generally 500 ~ 2000Pa. Therefore, it belongs to the medium-efficiency dust collector, and can be used for the purification of high temperature flue gas, is a widely used dust collector, more used in boiler flue gas dust removal, multi-stage dust removal and pre-dust removal. Its main disadvantage is that the removal efficiency of fine dust particles (<5μm) is low.

photobank (16)

Ceramic multi-tube dust collector is a dust removal equipment composed of several parallel ceramic cyclone dust collector units (also known as ceramic cyclone). It can be composed of general ceramic cyclone dust collector unit or DC cyclone dust collector unit, these units are organically combined in a shell, with a total intake pipe, exhaust pipe and ash hopper. Ash removal of ash hopper can have many forms of automatic ash removal, because this equipment is composed of ceramic cyclone pipe, which is more wear-resistant than cast iron pipe, and the surface is smoother, with acid and alkali resistance, so it can also be wet dust removal.
Application Scope and Advantages
It is suitable for dust control of various types and combustion modes of industrial boilers and thermal power station boilers. Such as chain furnace, reciprocating furnace, boiling furnace, coal throwing furnace, pulverized coal furnace, cyclone furnace, fluidized bed furnace and so on. For other industrial dust, the dust collector can also be used to treat, but also to use the dust collector for cement and other practical value of dust recovery.

Technical parameters list

Type Flow ratem3/h Filter aream2 Filter speedm/min Cleaning efficiency

emissions

mg/m3

ZXMC-60-2.5 4320~7560 60 1.2~2.1 95% ≤30-50
ZXMC-80-2.5 5760~10080 80 1.2~2.1 95% ≤30-50
ZXMC-100-2.5 7200~12600 100 1.2~2.1 95% ≤30-50
ZXMC-120-2.5 8640~15120 120 1.2~2.1 95% ≤30-50
ZXMC-140-2.5 10080~17640 140 1.2~2.1 95% ≤30-50
ZXMC-160-2.5 11520~20160 160 1.2~2.1 95% ≤30-50
ZXMC-180-2.5 12960~22680 180 1.2~2.1 95% ≤30-50
ZXMC-200-2.5 14400~25200 200 1.2~2.1 95% ≤30-50
ZXMC-220-2.5 15840~27720 220 1.2~2.1 95% ≤30-50
ZXMC-240-2.5 17280~30240 240 1.2~2.1 95% ≤30-50
ZXMC-260-2.5 18720~32760 260 1.2~2.1 95% ≤30-50
ZXMC-280-2.5 20160~35280 280 1.2~2.1 95%

≤30-50



Application

pro-4



Packaging and Shipping

xerhfd (13)xerhfd (6)










Product detail pictures:


Related Product Guide:

Our commission is to serve our buyers and purchasers with most effective good quality and aggressive portable digital goods for Reasonable price for In Electrostatic Precipitator - Cyclone Dust Collector – Xintian , The product will supply to all over the world, such as: Canberra, Mecca, Puerto Rico, We've been proud to supply our products and solutions to every auto fan all around the world with our flexible, fast efficient services and strictest quality control standard which has always approved and praised by customers.
The company account manager has a wealth of industry knowledge and experience, he could provide appropriate program according our needs and speak English fluently.
5 Stars By Olivia from United Arab Emirates - 2017.12.02 14:11
It is a very good, very rare business partners, looking forward to the next more perfect cooperation!
5 Stars By Erin from San Francisco - 2017.06.16 18:23
