Comparison and selection of several horizontal conveying equipment

In the cement plant, the most used equipment is the conveying equipment, of which the horizontal conveying equipment accounts for more than 60%. The most common horizontal conveying equipment for conveying powder materials is screw conveyor, FU chain conveyor, and air conveying chute. In order to improve everyone’s understanding and selection of horizontal conveying equipment, Zhengzhou Hongxin Machinery compares the characteristics of the three types of equipment as follows:

 (1) Screw conveyor

 The screw conveyor has the advantage of a wide range of applications. It can transport raw meal, cement, pulverized coal, etc. It can be used for both horizontal transportation and inclined transportation within 20°; it can transport both dry powder and sticky wet. materials. However, it has large resistance, high power consumption, many wearing parts, large maintenance workload, high installation accuracy requirements, and difficult sealing.

 (2) FU chain conveyor

The FU chain conveyor has low noise, low energy consumption and no powder pollution during operation. In addition, it does not need to put an oil cup every 2~3m like the screw conveyor, so the maintenance is very convenient, and it has been widely used in recent years. It is especially suitable for occasions with long conveying sequence and large wear. When the conveying distance of the surface screw conveyor exceeds 30m, the conveying shaft is long and not easy to be concentric. It often needs to be driven at both ends, and the power consumption is large. Although the FU chain conveyor has many advantages to replace the butterfly rotary conveyor, practice has proved that the maintenance cost of the FU chain conveyor is not low.

 (3) Air conveying chute

 Air conveying oblique precision is a conveying equipment that uses air to make solid particles flow in a fluidized state. It belongs to dense phase fluidized conveying. Compared with screw conveyors and FU chain conveyors, it has the following advantages: simple structure, easy Maintenance and repair, no moving parts, low wear and durability; polyester cloth as a breathable layer, long service life; good sealing, no noise, large conveying capacity; conveying direction can be changed, which is convenient for multi-point feeding and multi-point unloading; low power consumption , safe and reliable operation, etc. The disadvantage is that it cannot convey bulky sticky and wet materials, and cannot be conveyed upwards. It can only be conveyed at a certain downward slope. Generally, the conveying distance does not exceed 100m. When the conveying distance is large, the drop will be large, causing difficulties in process layout and civil engineering design. In addition, in order to exhaust, it is necessary to add a simple exhaust device at the rear of the air chute, such as using a single-machine dust collector or using a simple cloth bag to exhaust.

sadsadasdasd


Post time: Mar-02-2022
